D ? J&JK SERIES
SUBMINIATURE
CONNECTOR
Accessories/EMI prevention overmolding cover
MOLD COVER
Features –––––––––––––––––––––––
? This cover completely encloses all wire connections to the
connector, and its braided wire crimp section ensures a reliable
ground connection. The result is excellent shielding.
? This cover is sturdy enough to withstand the high pressure
necessary during overmolding. It can thus be finish-molded directly.
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Applicable cable diameter
J series
9
15
25
Circuits
JK series
15
?
?
Cable O.D.(mm)
8.6 ±0.2
7.6 ±0.2
8.6 ±0.2
Note: Contact JST for cables other than those listed above.
Ferrule
L
Circuits
J series JK series
Ferrule
φD
Dimensions (mm)
T
L
9?25
15
15
?
A
B
A
B
8.0
11.3
7.0
10.5
0.5
0.6
0.5
0.6
4.0
8.0
4.0
8.0
RoHS compliance
Mold cover A
Mold cover B
JK-MC15A-3
J-MC15A
J-MC25A-4
JK-MC15B-3
J-MC15B
J-MC25B-4
18.0
18.0
18.0
18.0
37.0(37.6)
39.0
37.0(37.6)
39.0
*Dimensions in (
the J-MC15A.
) are those for
*Dimensions in (
the J-MC15B.
) are those for
RoHS compliance
4
